| Specification | |||
| Material | Name | Grade | |
| AISI A6 AISI 01 SK-5 SKD11 4145H MOD 4140 4340 4330V SAE 52100 8620 |
|||
| Stainless Steel | SUS303 SUS304 SUS316 SUS316L 17-4PH 15-5PH H1025 9Cr 13Cr |
||
| Aluminium Alloys | AL6061 AL6082 AL7075 AL8081 |
||
| Copper Alloys | Bearing Bronze Brass C36000 CU1100 Tungsten/Copper |
||
| Engineering Plastics | PEEK PTFE UHMW-PE Delrin ABS Nylon |
||
| Capability | Machining | Product Size | Tolerance |
| CNC Turning | φ1 - φ160 * 550 mm | +/-0.003 mm | |
| CNC Milling | 1270 * 508 * 635 mm(max) | 1+/-0.001 mm | |
| Grinding | 1200 * 600 * 400 mm(max) | +/-0.001 mm | |
| Surface finishing | Anodising Clear, Black, Blue, Green, Gold, Red Hard Nodising Clear, Black Alodine MIL-C-5541 Hard Chrome Plating / Decorative Chrome Plating Electroless Nickel Plating Zinc Plating, Blue, White, Red, Yellow, Black Titanium Plating/Copper Plating/Gold / Silver Plating Black Oxide/Black Oxide for Stainless Steel QPQ Teflon Coating/Powder Paint Electro Chemical Polish |
||
| Heat treatment | Passivation of Stainless Steel Screen Printing / Laser Engraving Plasma Nitridation/Gas Nitridation/Carbon Nitridation Carburize/QuenchingTempering |
||
| Drawing Format | IGS,STP,X_T ,DXF,DWG , Pro/E, PDF | ||
| Inspection instrument | Projector, CMM, Altimeter,Micrometer, Height Gauge, Thread Gauge, Calipers, Pin Gauge etc. | ||
| Designs | Customer supply 2D/3D drawing | ||
| Lead time | 7 days for Sample; 15~21 days for Main production | ||
| Packing | EPE foam wrapped, wooden case. or as per request | ||
| Logo | OEM | ||
